Esta resistente y flexible cinta de impresión térmica está disponible en rollos continuos o precortados y en diversos colores, incluido el blanco. En combinación con nuestras cintas de tinta HiQ especiales, garantiza la obtención de óptimos resultados.
Estoy interesado en este productoLa cinta HiQ desarrollada por Thermopatch lleva años siendo el producto de referencia a nivel mundial. Aúna una gran calidad de impresión y perfecta adhesión, siendo resistente al lavado industrial. Es muy resistente y puede preimprimirse con un texto o logotipo en cualquier combinación de colores.
La cinta HIQ está disponible en varios anchos y tamaños troquelados. No admite plancha.
También disponible con soporte autoadhesivo: Hytex.
Junto con el blanco, la cinta HiQ está disponible en los siguientes colores (Hytex a petición):
Los colores mostrados pueden ser diferentes de los colores reales.
HiQ FR
HiQ FR es la elección correcta para ropa (de trabajo) donde las propiedades ignífugas o piro-retardantes son esenciales. Esta variante resistente al calor tiene las mismas propiedades que HiQ pero también cumple con las estrictas normas ISO 15025 y 15797. HiQ FR también está disponible en versión continua o troquelada.
HiQ-Clean
La serie HiQ ahora se ha ampliado con la introducción de HiQ-Clean. La cinta de esta gama tiene una capa adhesiva diferente, lo que permite aplicar la cinta a tejidos de barrera y materiales sintéticos similares. Esto incluye ropa de trabajo especializada en las industrias microelectrónica, farmacéutica y nuclear.
Este tipo de cinta también es ideal para textiles en entornos de salas limpias. Sin embargo, no es adecuado para ropa quirúrgica que se esteriliza en autoclave. HiQ-Clean está disponible como cinta continua o troquelada con las mismas dimensiones que otros productos de la serie HiQ.
HiQ-tape/Hytex | |
HiQ-Clean | |
HiQ-FR |
Available media for HiQ, HiQ-FR and HiQ-Clean
Colours HiQ: white, yellow, orange, red, pink, blue, green, high visibility yellow and mint green.
HiQ FR and HiQ-Clean are only available in white.
Inks
A black ink ribbon is supplied as standard in a boxed set.
Ink is also available in red, green, and blue.
Physical properties
Wash resistant up to 95 °C industrial laundry washing.
High heat-sealing temperatures.
Suitable for all textile which allows the thermoplastic adhesive to penetrate and bind itself to it and which is resistant to the advised heat seal application temperatures.
HiQ:
Thermal transfer printable top layer
Polyester cotton textile
Thermoplastic adhesive
HiQ tape
Article code | Width | Core |
HiQ30 | 30 mm | 50 mm |
HiQ35 | 35 mm | 50 mm |
HiQ40 | 40 mm | 50 mm |
HiQ50 | 50 mm | 50 mm |
HiQ60 | 60 mm | 50 mm |
HiQ70 | 70 mm | 50 mm |
HiQ80 | 80 mm | 50 mm |
HiQ90 | 90 mm | 50 mm |
Other sizes available upon request.
HiQ die-cut tape
Article code | Width | Core |
HIQDC 4116 | 41 x 14,4 mm | 50 mm |
HIQDC 4619 | 46 x 19 mm | 50 mm |
HIQDC 6312 | 63 x 12,7 mm | 76 mm |
HIQDC 7038 | 70 x 38 mm | 76 mm |
HIQDC 7625 | 76 x 25 mm | 76 mm |
HIQDC 8019 | 80 x 19 mm | 76 mm |
HIQDC 8030 | 80 x 30 mm | 76 mm |
HIQDC 9025 | 90 x 25 mm | 76 mm |
HIQDC 9038 | 90 x 38 mm | 76 mm |
HIQDC 9050 | 90 x 50 mm | 76 mm |
Other sizes available upon request.
Hytex
Thermal transfer printable top layer
Polyester cotton textile
Thermoplastic adhesive
Pressure sensitive adhesive
Carrier paper
Article code | Width | Core |
HYTEX 4114 | 41 x 14,4 mm | 50 mm |
HYTEX 5319 | 53 x 19 mm | 50 mm |
HYTEX 6312 | 63 x 12,7 mm | 76 mm |
HYTEX 8414 | 84 x 14,4 mm | 76 mm |
HYTEX 8423 | 84 x 23,4 mm | 76 mm |
HYTEX 8436 | 84 x 36,1 mm | 76 mm |
HYTEX 8448 | 84 x 48,4 mm | 76 mm |
HYTEX 9048 | 90 x 48,4 mm | 76 mm |
Other sizes available upon request.
HiQ Clean
Wash resistant up to 60 °C industrial laundry washing.
Suitable for all textile which allows the thermoplastic adhesive to penetrate and bind itself to it and which is resistant to the advised heat seal application temperatures.
Physical properties
Thermal transfer printable top layer
Polyester textile
Thermoplastic adhesive
Handling and storage
Keep away from oxidizing agents, from strongly alkaline en strongly acid materials.
Store out of direct sunlight, in a cool and dry place.
Shelf life: estimated more than 2 years under mentioned conditions.
Precautions
No specific safety measures are required when working with this product. We advise always to ventilate well at heat-sealing activities, since vapours may occur from any material such as textiles being processed.
Article code | Width | Core |
HiQ30-CLEAN | 30 mm | 50 mm |
HiQ40-CLEAN | 40 mm | 50 mm |
HiQ50-CLEAN | 50 mm | 50 mm |
HiQ60-CLEAN | 60 mm | 50 mm |
HiQ70-CLEAN | 70 mm | 50 mm |
HiQ80-CLEAN | 80 mm | 50 mm |
HiQ90-CLEAN | 90 mm | 50 mm |
Other sizes available upon request.
All HiQ media is supplied as a boxed set containing the following: 2 x 50 meter long rolls of label tape, 1 x 104 meter long ink ribbon, and a cleaning pad for cleaning the printhead when replacing the ink ribbon.
